What a Recipe is

A Process Recipe is a tree that describes the full sequence of steps to complete a coating. It drives:

Work Order generation (one WO per operation node)
The travelling sheet / job card operators see
The CoC's process listing
Tablet Station step-by-step guidance

Menu: Plating → Operations → Process Recipes.

Recipes list

Box ① + New Recipe (top-left). Box ② columns (Name, Code, Version, Active). Box ③ click a row to open it.

The node hierarchy

Every recipe is a tree of nodes. Four node types:

Type	Role
`recipe`	Root of the tree. One per recipe.
`sub_process`	Logical group (e.g. "Pre-treatment"). Not executed on its own.
`operation`	A WO-generating step (e.g. "Alkaline Clean"). Each becomes one mrp.workorder.
`step`	Instruction-only child of an operation (e.g. "dwell 3 min at 60 °C"). Appears on the travelling sheet.

The WO generator walks the tree pre-order and emits one WO per operation node that passes its opt-in/out rules.

The tree editor

Open a recipe and click Open Tree Editor. The OWL-based editor lets you:

Add Child Node — green + button on any node.
Drag-drop — re-order or re-parent nodes within valid constraints.
Delete — trash icon; cascades to children.
Duplicate — for sibling nodes that differ slightly.
Icon picker — choose from the 24 curated plating icons.

Node fields

Each node has:

Field	Purpose
Name	What the operator sees
Node Type	recipe / sub_process / operation / step
Sequence	Ordering among siblings
Icon	Visual cue
Estimated Duration (min)	Used in WO `duration_expected` + dwell display
Auto-Complete	Skip operator sign-off
Customer Visible	Appears on CoC + portal
Is Manual	Yes = operator-driven; No = automated
Requires Sign-off	QA/lead must approve before batch advances
Opt-in/Out	`disabled` (always run) / `opt_in` (skipped unless requested) / `opt_out` (run unless excluded)
Work Centre	Where the WO lands (FP WC → MRP WC mapping)
Shop Role	Which operator role can run this step
Operator Inputs	Structured fields the operator fills (measurements, pass/fail, photos)

Opt-in / opt-out semantics

disabled: the node always runs. Most common default.
opt_in: skipped on new jobs. Planner must explicitly enable per MO (via the Recipe Config wizard). Use for optional tests / non-standard treatments.
opt_out: runs on new jobs unless explicitly excluded. Use for common-but-sometimes-skipped steps (e.g. first-piece inspection on small re-orders).

The MO's Recipe Config wizard surfaces every opt-in/opt-out node so the planner can set per-job.

Operator inputs

Click a node → Operator Inputs tab. Add rows like:

Label	Type	Required
Pre-plating pH	Number	✓
Dwell time (min)	Number	✓
Visual inspection	Pass/Fail	✓
Rack photo	Image	—

These render on the Tablet Station as prompts the operator must answer before advancing to the next step.

Versioning

Any substantive edit to a recipe increments version. MOs currently running against the old version continue with a pinned copy (so mid-flight changes don't break the shop floor).

To force existing MOs to re-read a new recipe version: open each MO → Actions → Re-sync Recipe.

Reference implementations

Fusion Plating ships with 5 data-seeded recipes:

ENP-ALUM-BASIC — Electroless Nickel on aluminium.
ENP-STEEL-BASIC — EN on steel.
ENP-SP — EN, Special Process (aerospace).
ANODIZE — Type II sulfuric anodize.
CHEM_CONVERSION — Trivalent chromate.

Clone any of these as a starting point for a custom variant. Open → Duplicate → edit.

What can go wrong

No WOs generated from a confirmed SO

The coating's recipe_id is blank, or the recipe has no operation nodes. Check the coating config and the recipe tree.

Operator says "step X is missing"

Either the node is opt_in and the planner didn't enable it, or it's been archived. Check the Recipe Config wizard + the tree editor.

First-piece sign-off isn't firing

Node's Requires Sign-off checkbox is off. Turn it on in the tree editor.
